Diagnostics and assessment of the technical condition of pipelines
_______________________________________________________________________________
In-line Diagnostics of Pipeline Sections
- Inline diagnostics technology includes the following main stages:
- Cleaning from asphalt-resinous, paraffinic and pyrophoric deposits, foreign objects, scale and electrode residues;
- Calibration (determination of the minimum flow area of the pipeline);
- Profilometry (identification of dents, corrugations, ovality);
- Wall diagnostics with in-line magnetic (MFL and TFI) and ultrasonic flaw detectors (corrosion, delamination, cracks and crack-like defects, etc.);
- Decoding and interpretation of diagnostic information and preparation of the final report.
If necessary, a calculation for durability (residual life), calculation of strength (maximum allowable working pressures) and industrial safety expertise are carried out.
Ultrasonic Thickness Gauges
- Ultrasonic thickness gauge VZLOT UT - general industrial - Designed to measure the thickness of products and objects from various materials, measure the propagation speed of ultrasound in a material with a known thickness value.
- Ultrasonic Thickness Gauge 38DL PLUSOlympus - The versatile 38DL PLUS has a wide range of applications: from measuring wall thinning of corroded pipes using dual element transducers to highly accurate thickness measurement of thin or multilayer materials using single element transducers.
- Ultrasonic Thickness Gauge DM5E - for use in the harshest conditions, for measuring wall thickness of pipelines, pressure vessels and tanks in the oil and gas industry, as well as the petrochemical and energy industries.
Internal Pipeline Diagnostics
- Piston for in-line diagnostics - Service work to determine internal corrosion, the integrity of the internal section of the pipeline.
- Double-sided cleaning pistons R = 5D, R = 3D or R = 1.5D, depending on the pipeline rotation angles - for cleaning from deposits and liquid in pipelines.
Ultrasonic Flaw Detectors
- Ultrasonic flaw detector А1212 MASTER - Inspection of welded seams, search for places of corrosion, cracks, internal delamination and other defects, determination of coordinates and evaluation of parameters of defects such as discontinuities and material homogeneity in metal and plastic products, measurement of product thickness.
- Ultrasonic flaw detector UD9812 URALETS - for non-destructive testing of metal and plastic products with a thickness of 0.5mm to 6000mm. for the presence of defects such as discontinuity and homogeneity
- Ultrasonic flaw detector USD-50 - non-destructive expert inspection of welded joints and base metal.
- Ultrasonic scanner USD-60-8KWeldSpector flaw detector - for ultrasonic flaw detection and thickness measurement as part of automated and mechanized control systems.
